Norgas VersaMag Water Meter — 5/8×3/4" Hot, Polymer, Pulse Output

The hot-water VersaMag — same polymer body, same removable register, rated to 160°F.

• Nominal 3/4" (19 mm)
• Hot water, 160°F (71°C) max
• Flow 1–20 GPM normal, 1/4 GPM minimum
• Maximum working pressure 150 PSI
• 50% glass-reinforced nylon polymer
• Horizontal or vertical installation
• Removable register
• Pulse output standard, 1/1 gal or 1/10 gal
• AWWA C708, NSF listed, UL2043 plenum rated
• NTEP California approved, Massachusetts approved
• 0.75 lb
